LESSON Smart Display Launches LS045I08-MP-V1 4.5" MIPI DSI TFT LCD Module with High-Speed Interface
LESSON Smart Display Technology Co., Ltd. announces the release of the LS045I08-MP-V1, a 4.5-inch TFT LCD module featuring MIPI DSI interface with optimized rise/fall timing specifications for high-speed data transmission in embedded display applications.
Product Overview
The LS045I08-MP-V1 is a 4.5-inch TFT LCD module designed for applications requiring high-speed data transmission with precise timing control. Based on the MIPI DSI (Display Serial Interface) standard, this module offers excellent signal integrity and reliable performance in demanding environments.
Technical Innovation: The LS045I08-MP-V1 implements advanced timing control with differential rise/fall times under 150ps, ensuring reliable high-speed data transmission for applications requiring precise display synchronization and minimal signal distortion.
Technical Specifications
| Parameter | Specification | Unit |
|---|---|---|
| Model Number | LS045I08-MP-V1 | - |
| Display Size | 4.5 inch | Diagonal |
| Interface | MIPI DSI | High-speed serial |
| Differential Rise Time (Clock) | ≤150ps | Picoseconds |
| Differential Fall Time (Clock) | ≤150ps | Picoseconds |
| Differential Rise Time (Data) | ≤150ps | Picoseconds |
| Differential Fall Time (Data) | ≤150ps | Picoseconds |
| Reference Voltage | 0V Reference for DSI-CLK+/- | Differential Input |
| Swing Voltage | Full HS Swing Voltage | High-Speed Mode |
| Compliance | ROHS | Environmental Standard |
Timing Specifications
Based on Table 47: Rise and Fall Timings on Clock and Data Channels, the LS045I08-MP-V1 ensures precise signal timing with:
- Differential Rise/Fall Time for Clock (tDRTCLK/tDFTCLK): ≤150ps
- Differential Rise/Fall Time for Data (tDRTDATA/tDFTDATA): ≤150ps
- 20% to 60% transition timing for reliable signal integrity
- Full High-Speed swing voltage for optimal signal transmission
Key Features & Benefits
High-Speed MIPI DSI Interface
Supports high-speed data transmission with minimal latency, ideal for video and graphical applications requiring fast refresh rates.
Precise Timing Control
Optimized rise/fall timing specifications ensure signal integrity and reduce electromagnetic interference in sensitive applications.
Differential Signaling
DSI-CLK+/- and DSI-Dn+/- differential pairs provide noise immunity and reliable data transmission over longer distances.
ROHS Compliance
Environmentally friendly design meeting international standards for hazardous substance restrictions.
Target Applications
Industrial & Automation
- Human-Machine Interfaces (HMI)
- Industrial Control Panels
- Test & Measurement Equipment
- Factory Automation Displays
Medical & Healthcare
- Portable Medical Devices
- Patient Monitoring Systems
- Diagnostic Equipment Displays
- Medical Instrument Interfaces
Consumer Electronics
- Smart Home Controllers
- Portable Multimedia Devices
- Gaming Accessories
- Digital Photo Frames
Automotive & Transportation
- Aftermarket Car Displays
- Fleet Management Systems
- Navigation Device Screens
- Transportation Information Displays
Availability & Ordering Information
The LS045I08-MP-V1 is available for sampling and volume production. Evaluation kits and technical documentation are available upon request.
Sample Requests
Contact our sales team to request evaluation samples and technical support.
Volume Production
Standard lead time: 6-8 weeks for volume orders. Custom configurations available.
Technical Support
Comprehensive technical documentation, reference designs, and application notes available.
