Introduction
This document is the official product specification for the LSC070I10-R-V1, a 7.0-inch transmissive a-Si TFT-LCD module developed by LESSON Smart Display Technology Co., Ltd. Featuring a standard resolution of 1024(RGB)×600, 16.7 million colors, and a parallel RGB interface, this module is a classic and widely compatible display solution. With its integrated touch panel (COF type, G+G structure), it serves as a reliable choice for industrial HMIs, consumer appliances, automotive aftermarket, and any system using a traditional RGB display controller.
Key Specifications
- Brand & Model: LESSON Smart Display LSC070I10-R-V1
- Screen Size: 7.0 inches (diagonal) | 165x100x5.1mm
- Active Area: 153.84x85.63mm
- Driver IC: JD9165
- Display Technology: Transmissive type a-Si TFT-LCD
- Display Mode: IPS, TRANSMISSIVE, NORMAL BLACK
- Module Type: COG + FPC + B/L + CTP
- Display Resolution: 1024(RGB) × 600 pixels
- Display Colors: Up to 16.7 Million Colors
- Interface: Parallel RGB (inferred from pin description: R0-R7, G0-G7, DCLK)
- Touch Panel: COF type; IC: GT911; Structure: G+G (Glass+Glass)
- Optical Characteristics (Typical):
- LCM Luminance: 420 cd/m² (TYP), 380 cd/m² (MIN) @ 20mA/LED
- Contrast Ratio: 900:1 (TYP)
- NTSC Ratio: 70% (TYP)
- Transmittance: ≥85%
- Mechanical Specs: Cover glass hardness: 6H.
- Operating Temperature: -20°C to +60°C, ≤85% RH
- Storage Temperature: -30°C to +70°C, ≤85% RH
- Backlight: LED WHITE, 3 series, 9 parallel (3S9P). Vf=8.4~10.5V, If=180mA.
- Pin Description: 50-pin connector with RGB data lines (R0-R7, G0-G7, B0-B7 likely), control pins (DCLK, SHLR, UPDN, RSTB), and power supplies (VGH, VGL, AVDD, VCOM).
- Environmental Compliance: RoHS Compliant
General Description
The LSC070I10-R-V1 is a traditional RGB interface module, offering direct compatibility with many microcontrollers and application processors that have a built-in LCD controller. The 7-inch 1024x600 format is a common industrial size. The specification provides excellent optical performance data, details on the touch panel structure and IC, clear backlight electrical requirements, and a full pinout for the parallel interface. It also calls out key mechanical properties like hardness and transmittance.
Key Features
- Parallel RGB Interface: Simple, direct, and widely supported.
- IPS Panel: Good viewing angles.
- Detailed Optical Specs: Luminance, contrast, gamut, and transmittance.
- Defined Touch Solution: GT911 with G+G structure.
- Clear Backlight Drive Specs: 3S9P, voltage, and current.
Application Scenarios
- Industrial HMIs: PLC interfaces, control panels.
- Home Appliances: Smart thermostats, high-end oven controls.
- Automotive Center Displays: Aftermarket head units.
- Test & Measurement Equipment: Bench instrument displays.
- Consumer Electronics: Portable DVD players, etc.
Conclusion
The LESSON Smart Display LSC070I10-R-V1 is a solid, no-nonsense display module with a traditional interface. Its strength lies in its comprehensive specification of both display and touch components, making it easy to evaluate and integrate into systems designed around parallel RGB video.
